Door Tablet AIO+
available
Workspace Signage Touch Display
Our purpose-built premium display is placed outside your meeting spaces. Now with a + for additional features
Manufactured by:
Easy to Install
Works “out of the box” and comes with all the fixtures and fittings needed to get it up where it will be seen. It’s easy to mount on any surface including glass, brick and metal.
Readable at Wide Viewing Angles
The IPS display ensures the screen can be read comfortably at a distance and at wide angles so there’s no need to get up close to read what’s being displayed.
Sturdy
The screen is tempered glass which means it is tough, easy to clean and will not shatter, crack or deteriorate excessively with time or heavy use. It’s built to last and stay looking good.
Attractive
It is sleek and slim (3cm deep) with a 10.1” high resolution (1280 x 800 dpi) full color touchscreen; meaning it not only looks good, but the display is easy to read and provides smooth interaction.
LED Lighting on Front and Sides
Bright and colorful LED lights on the front and sides of the Door Tablet AIO signal that a room is free or busy and are visible from distance - so there is no need to walk up to a room to see its status.
eMMC Storage
The AIO has 8GB eMMC storage. Reliable read/write data settings ensure existing data will not be corrupted when a sudden power loss occurs.
RFID Supports for NFC & HiD
RFID/Mifare/FeliCa/HiD card types enable easy user identification when entering rooms by tapping in and out of meetings. Administrators can audit room usage and decide who can enter rooms if the door unlocking feature is enabled.
Power over Ethernet (PoE+) Built-in
With no need to rely on Wi-Fi signals, a single PoE+ cable powers the AIO giving you the benefit of full power management, saving costs and the environment. Shut down and restart screens as needed.
Features
CPU |
ARM quad-core 1.6GHz |
Memory |
2GB DDR3 |
Storage |
8GB eMMC |
Display Orientation |
Landscape/Portrait |
Audio codecs |
MP3 |
Colors |
Black / Silver / White |
PoE+ |
Yes |
Bluetooth / Wi-Fi |
Yes |
Display
Size |
10.1” |
Resolution (Max.) |
1280 x 800 |
Brightness |
300 nits |
Contrast ratio |
1000 : 1 |
Viewing angle (H/V) |
178/178 |
I/O Interface
Ethernet |
RJ45 (10M/100M) |
USB |
2x USB2 type / Micro USB |
Analog Stereo out |
3.5mm stereo |
Storage Expansion |
Micro SDHC slot |
Speaker |
2W x 2 |
Mechanical
Dimensions without stand |
261.1 x 193.3 x 27mm
10.28” x 7.61” x 1.06” |
Weight |
710g / 1.56 lbs |
Mounting |
Glass / Surface / Recessed |
Housing |
Plastic |
Environment |
Operating Temp. 0~50°C
Humidity: 10 to 85%
(non-condensing) |
Power |
DC 12V, 1.5A |
Certification |
CE/FCC/RoHS |
See the
Warranty Statement
